DH Series 2 Channel Class H High Stability Power Amplifier
    Publish time 2020-03-16 15:03
DH Series 2 Channel Class H High Stability Power Amplifier
DH Series

2 channel Class H High Stability Power Amplifier








                                  Specifications:

 Model No.  DH3600  DH4500  DH6000  DH7000  DH9000
Channel number 2 inputs, 2 outputs 2 inputs, 2 outputs 2 inputs, 2 outputs 2 inputs, 2 outputs 2 inputs, 2 outputs
Height  88mm ( 2U) 88mm ( 2U) 88mm ( 2U) 88mm ( 2U) 88mm ( 2U)
Circuit category CLASS AB CLASS AB CLASS H CLASS H CLASS H
Output power stereo 4Ω  500Wx2  700Wx2  1000Wx2 1200Wx2  1500Wx2
Output power stereo 8Ω  350Wx2  450Wx2  600Wx2  700Wx2  900Wx2
Bridged output powr 8Ω NA 1800W 2400W 2600W
  Input sensitivity   0db(0.775V rms) 1.0V/26dB
 Frequency response   20-20000Hz (±0.3dB)
 Slew rate   ≥30V/us
 Damping factor   ＞400:1 (10Hz-400Hz)
 Cross talk     ＞70dB@1KHz
 S/N ratio   ＞100dB
 THD+N   ＜0.1%,1K Hz
 IMD  ＜ 0.2% ( 8Ω ,1KHZ@1W)
Protection Fully automatic protection against short circuit, over-load, over-heat, switch on/off and radio frequency interference or mismatched load.
 Dimensions (WxHxD) 483x88x445mm                                                               483x88x462mm
Net Weight (kg) 15.5 16.65 17.45 20.3 20.4








Product Features:


DH series are designed specially for entertainment project,inheriting high stability and nice timbre from ON
power amplifier. The main features are as the following:

1.  Class-H circuit.

2.  Novel enclosure design with compact structure and exquisite workmanship.

3.  Excellent signal conversion with very less harmonic and intermodulation distortion.

4.  Perfect protection system with peak detection circuit to protect the speakers. Full protection against
    short circuit, over-load, over-heat, power switching on/off, low voltage, etc.

5.  Pure and natural timbre with crystal bright medium and high frequency, plump and elastic bass.

6.  Full function high speed protection circuit with quality U transformer and class H electricity.

7. Nice cooling system, ensuring a long-lasting work reliability.
