1U 2 Channel Universal Power Supply 90-265V PFC Digital Power Amplifier
Publish time 2020-03-26 17:29
1U 2 Channel Universal Power Supply 90-265V PFC Digital Power Amplifier
AT SERIES
. Powerful output 350-2800W 8 ohm per channel in small and compact shell space. . Universal power supply voltage range 90-264V. No worry about unstable power voltage. . Compact structure of Class D PCB, SMPS Power supply module.
. Smaller size and lighter weight. Easy to install and move.
. 2 ohm stable
Specifications:
Model No.
AT-350
AT-500
AT-650
AT-800
AT-900
AT-1100
AT-1800
AT2100
AT2400
AT2800
Stereo Output power 8Ω
350Wx2
500Wx2
650Wx2
800Wx2
900Wx2
1100Wx2
1700Wx2
2100Wx2
2400Wx2
2800Wx2
Stereo Output power 4Ω
580Wx2
800Wx2
1050Wx2
1300Wx2
1400Wx2
1800Wx2
2800Wx2
3400Wx2
3800Wx2
4500Wx2
Stereo Output power 2Ω
1100Wx2
1100Wx2
1250Wx2
1500Wx2
1750Wx2
2000Wx2
3600Wx2
4000Wx2
5000Wx2
5500Wx2
Bridged output 8Ω
1160W
1600W
2100W
2600W
2800W
3600W
5600W
6800W
7600W
9000W
Bridged output 4Ω
1600W
2200W
2800W
3300W
3500W
4000W
7200W
8000W
10000W
11000W
Voltage Gain
40.8/38.6/32
40.8/38.6/32
41.2/39/32
42.7/40.5/32
40.8/38.6/32
41.2/39/32
42.7/40.5/32
42.7/40.5/32
42.7/40.5/32
42.7/40.5/32
THD (total harmony distortion)
≤0.035% (@ 8Ω,1kHz,1/8 rated power)
IMD(intermodulation distort.)
≤0.15% (@ 8Ω,1kHz,1/8 rated power)
S/N Ratio (20Hz-20Khz,4 Ohms)
>106dB A
Cross-talk (1kHZ, 4 Ohms)
>40dB
Frequency response
10Hz to 20k Hz,+/-1dB
Input impedance
balanced 20K/ non-balanced 10K
Damping factor (10-400Hz,8Ohms)
≥600
Slew Rate
≥20v/uS
Input sensitivity
0.775V,0dB
Protection functions
Amplitude limit , and protections againts short circuit ,over-load, overheat, direct current, radio-interference , on/off switching and muting.
Control knobs
power ON/OFF switch,VOLUME control in front panel . STEREO/BRIDGE/MONO switch in rear panel .
LED indicators
CLIP/-10dB/SIGNAL/MONO/BRIDGE/STATUS indicators in front panel
Power delay
4 seconds
Input interface
XLR input socket
Output interface
SPEAKON connector
Dimensions (WxHxD) mm
483x44x230
483x44x230
483x44x230
483x44x230
483x44x230
483x44x230
483x44x280
483x44x280
483x44x340
483x44x340
Net weight
5.3kg
5.5kg
5.8kg
6.2kg
6.4kg
6.5kg
7.2kg
8.10kg
8.8KG
9.2kg
Product Features:
DOLSI AT Series are digital power amplifier with Class D circuit category, a new milestone in amplfier development. PFC ( Power Factor Correction) technology is used in AT series so the amplifiers can work well in wide power supply range ~90-260V. Advanced Class D PCB module and SMPS power supply module are used to obtain high efficiency and stability. It has very high power density, which makes the amplifier to reach powerful output in a very small shell space. . Universal operating voltage 90-264VAC. No worry about unstable power voltage. . Compact structure with only 1U height and 9" depth and light weight, easy to move and install. . Fixed switch frequency Class-D PCB module. . Soft resonant switching power supply LLC module. . High efficiency loud speaker EMF absorption system. . Unique peak clipping limiter and ripple Elimination. . Low electricity consumption. . Nice cooling system with quality fans to make wind flow front to the rear. . Accurate volume control, switch on/off, signal, clip and protection LED light in front panel. . Fully automatic protections against direct current protection, over heat, over load, on/off switching, RF, and amplitude limit. . XLR balance input and professional SPEAKON output connectors. . Stereo ,bridge and mono mode selection pull switch is set on back panel. . Good choice for applications that need high power output , for example, live show, outdoor event, stadium, flow performance ... etc.
